Saturday, November 29, 2014

Windows Thread Suspension Internals Part 2

In the last blog post I talked about both NtSuspendThread and PsSuspendThread kernel routines. If you didn't check the first part I recommend to check it first : here
This part is dedicated to KeSuspendThread and KiSuspendThread routines (fun stuff).
Let's get started by looking a KeSuspendThread : (Windows 7 32-bit SMP as usual)
(pseudo-C) :
A quick overview of KeSuspendThread shows that it's actually the one responsible of calling KiInsertQueueApc in order to queue the target thread's suspend APC in its kernel APC queue. But that's not the only thing happening here , so take it slow and go step by step into what routine does.

As you can notice we start first by raising the irql to DISPATCH_LEVEL, this means we're running in the same irql where the thread dispatcher does so our thread is guaranteed to be running on this processor until the irql drops below DISPATCH_LEVEL. As I'm on a multiprocessor machine this doesn't protect from accessing shared objects safely as another thread executing on another processor might access the object simultaneously. That's why a couple of locks must be acquired in order to continue the execution of the routine , the first lock that KeSuspendThread tries to acquire is the APC queue lock (Thread->ApcQueueLock). After acquiring the lock, execution continues and the thread's previous suspend count is saved , then it is compared with the maximum value that a suspend count might reach (0x7F). The irql is lowered to it's old value and a fatal exception is raised with status (STATUS_SUSPEND_COUNT_EXCEEDED) if the SuspendCount is equal to that value. As I mentioned in the last part PsSuspendThread calls KeSuspendThread within a try-except statement so the machine won't bugcheck as a result of that exception.
If the target thread's suspend count is lower that 0x7F (general case), a second check is done against Thread->ApcQueuable bit to check whether APCs can be queued to that thread or no. Here I want to mention that if you patch that bit using windbg or a driver of a given thread object that thread becomes immune to suspending and even termination as it is done also using an APC.
If the bit is set (generally the case also), the target thread's suspend count is incremented. Next , the routine checks if the thread isn't suspended nor frozen.
If that's also true a third check is done :
line 29 : if(Thread->SuspendApc.Inserted == TRUE) { ....
The SuspendApc is a KAPC stucture , and the Inserted field is a boolean that represents whether the APC was inserted in the APCs queue or not.
Let's start by seeing the else statement at line 38 first and get back to this check. So basically we'll be in the else statement if (SuspendApc.Inserted == FALSE) , it will simply set the APC's Inserted boolean to TRUE and then call KiInsertQueueApc to insert the suspend APC in the target's thread kernel APCs queue. KiInsertQueueApc is internally called by the exported KeInsertQueueApc.

The check at line 29 is confusing, since if the SuspendApc.Inserted is TRUE this already means that the suspend count is different than 0 so we won't even reach this if statement.As we'll see in a later article KeResumeThread is the routine that actually decrements the SuspendCount but it doesn't proceed to do so until it acquires the ApcQueue lock , so this eliminates the fact that KeResumeThread and KeSuspendThread are operating simultaneously on the same target thread (SMP machine). If this check turns out true for a reason , we acquire a lock to safely access and modify the SuspendSemaphore initialized previously by &Thread->SuspendSemaphore and then decrement the Semaphore Count to turn it into the non-signaled state apparently.
If the SuspendApc is now queued , its kernel and normal routines (KiSuspendNop and KiSuspendThread respectively) will be executed as soon as KiDeliverApc is called in the context of the target thread.
The SuspendApc is initialized in KeInitThread  this way :
Let's now take a look at KiSuspendThread normal APC routine :
It simply calls KeWaitForSingleObject to make the thread wait for the SuspendSemaphore to be in the signaled state.
The Suspend semaphore is also initialized in KeInitThread routine :
As you can see the count limit is set to 2 and the initial semaphore is 0. As we'll see later when talking about thread resumption : each synchronization object has a header structure defined as : _DISPATCHER_HEADER, this structure contains the synchronization object's Type (mutant , thread , semaphore ...) , Lock , SignalState fields and some other flags.
The SignalState field in a semaphore is the same as the semaphore count and the semaphore count must not exceed the limit. Semaphores ,when in signaled state (semaphore count > 0) , satisfy the wait for semaphore count threads and unsignal the semaphore. Means if 4 threads are waiting on a semaphore and it became in a signaled state with a semaphore count of 2 , 2 threads will satisfy the wait and the semaphore will become non-signaled. The next waiting thread won't get a chance to run until one of the released threads releases the semaphore , resulting in its semaphore count being incremented (signaled state).

Let's get back to the SuspendSemaphore now. As I said earlier, it is initialized as non-signaled in the first place so when a thread is suspended it'll stay in the wait state until the semaphore becomes signaled. In fact KeResumeThread is the responsible routine for turning the semaphore into the signaled state and then calling KiSignalSynchronizationObject to unlink the wait block and signal the suspended thread (future posts).

As we discovered together what happens when suspending a thread in detail , the next blog posts will be dedicated to talking about what happens when we call ResumeThread or ZwResumeThread. Stay tuned.

Follow me on twitter : here
- Souhail

Thursday, November 27, 2014

Windows Thread Suspension Internals Part 1

It's been a while since I haven't shared anything concerning Windows internals and I'm back to talk in detail about how Windows thread suspension and resumption works. I'm going to discuss the mentioned topics in this blog post and incoming ones. Even though it can be discussed in one or two entries but I'm quite busy with studies.

As you might already know Windows uses APCs (Asynchronous Procedure Calls) to perform thread suspension. This may form an incomplete image of what's going on in detail as other tasks are being performed besides queuing the suspend APC. I will share throughout this article the details about what's happening and some pseudo code snippets of the reversed routines (Windows 7 32-bit SMP).

Let's say that a usermode thread 'A' wanted to suspend a second usermode thread 'B' , it has to simply call SuspendThread with a previously opened handle to the target thread.
DWORD WINAPI SuspendThread(HANDLE hThread);
Upon the call we'll be taken to kernel32.dll then to kernelbase.dll which simply provides a supplementary argument to NtSuspendThread and calls it from ntdll.dll .
NTSTATUS NtSuspendThread(HANDLE ThreadHandle,PULONG PreviousSuspendCount );
The thread's previous suspend count is basically copied from kernel to *PreviousSuspendCount.
Ntdll then takes us to kernel land where we'll be executing NtSuspendThread.

- NtSuspendThread :
 If we came from usermode (CurrentThread->PreviousMode == UserMode), probing the PreviousSuspendCount pointer for write is crucial. Next, a pointer to the target thread object is obtained by calling ObReferenceObjectByHandle , if we succeed PsSuspendThread is called ; its return type is NTSTATUS and that is the status code returned to the caller (in PreviousMode) after calling ObDereferenceObject and storing the previous count value in the OUT (PreviousSuspendCount) argument if it's not NULL.

- PsSuspendThread :
Prototype : NTSTATUS PsSuspendThread(PETHREAD Thread,PULONG PreviousSuspendCount)
Here's a pseudo C manual decompilation of the routine code :

As you can see, PsSuspendThread starts with entering a critical region and then it tries to acquire run-down protection of the target thread to suspend , acquiring run-down protection for the thread guarantees that we can access and operate on the thread object safely without it being deleted. As you might already know a present thread object in memory doesn't mean that the thread isn't terminating or wasn't terminated simply because an object isn't deleted until all the references on that object are released (reference count reaches zero). The next check of the Terminated bit explains it , so if the thread is actually terminating or was terminated PsSuspendProcess return STATUS_THREAD_IS_TERMINATING. Let's suppose that our thread is up and running. KeSuspendThread will be called as a result and ,unlike the previous routines, will returns the previous count that we've previously spoken about. As we'll see later on KeSuspendThread raises a critical exception (by calling RtlRaiseStatus) if the thread suspend limit was exceeded (0x7F) that causes a BSOD if no exception handler is in place , so the kernel calls this function within a try-except statement. Upon returning from KeSuspendThread successfully , a recheck of the target thread is done to see if the thread was terminating while suspending , if that's true the thread is forced to resume right away by calling KeForceResumeThread (we'll see this routine in detail later when talking about thread resumption) and the previous suspend count is zeroed. Finally the executing thread leaves the critical region and dereferences the PreviousSuspendCount pointer with the value returned from KeSuspendThread or 0 in the case where KeForceResumeThread was called.

That's all for this short entry , in the next parts about thread suspension I'll talk about KeSuspendThread , the suspend semaphore and the KiSuspendThread kernel APC routine.

Follow me on twitter : Here

- Souhail.

Monday, October 13, 2014

ASIS CTF Finals 2014 - Satellite Reloaded Reverse 250 Writeup

I really enjoyed playing this CTF with Spiderz team and we ended at position 23.
This reversing challenge was for 250 points , and here's a brief write-up about it :
The binary expects a string as a command line argument and it starts in the beginning by decrypting a string stored statically at .data section. If the position of the character is an even number the character is xored by 0xD4, if it's an odd number the character is xored with 0xD5.
After decrypting , we get the following large equation :

As you can see, each element a[x] is actually the character of position 'x' in the string that we'll supply. Similarly to the Satellite task we're deal with the boolean satisfiability problem .
If you take a second look at the long decrypted string we've got , you'll see that each character (with the exception of a[220] which not referenced anyway) of the string is referenced exactly 3 times and it is always tested against another character which is static in the 3 cases. So to solve this we'll just rely on studying each 2 characters couples alone.
For example to make this statement true :
(a[12] | a[20]) & ( ! a[12] | !a[20]) & (!a[12] | a[20])
a[12] must equal :  0
a [20] must equal : 1
Another example :
(!a[22] | a[150]) & (a[22] | a[150]) & (a[22] | !a[150])
In this case both a[22] and a[150] must be equal to 1 to make this statement true.
In the string shared in pastebin above you'll see that in some cases there's a double NOT (! !) , we'll just remove it as it doesn't change anything.

So to script this we don't basically need to study the SAT algorithm any longer, we can just separate this long string into 2 arrays. Each element of the 2 arrays is a logical equation (ex : "( ! a[22]  |  a[50]  )" ).
The first array will only have the elements that have a NOT ('!') on the both chars or that doesn't have any NOTs in them (ex : ( a[55] | a[60] ) and this one ( ! a[70] | ! a[95] ) )
The other array will have all the equations that have a NOT preceding either one of the chars. (ex : ( ! a[22] | a[50] ).
The reason why I did this because in the case of the first example I gave (here it is :
(a[12] | a[20]) & ( ! a[12] | !a[20]) & (!a[12] | a[20]) ) there will be 2 occurrences of a[12] in the first array which makes it hard to decide whether it's equal to a 0 or 1 , here comes the 2nd array that I called "decide" that will decide by this equation : (!a[12] | a[20]) whether a[12] is 0 or 1 , which is 0 in this case.
So If only one instance of a given a[x] is found in the first array we can decide it's value directly , but if we have 2 instances we'll need to rely on the decide array.

Oh , I almost forgot , there's a character which isn't referenced in this string and which is a[220] . As the flag is generated based on our input, I tested the flag with this character set to 0 and 1. And it basically worked for 0.

Here's the script I wrote and described in this write-up (got us some bonus points though :D ) :

Cheers :).

Monday, September 22, 2014

CSAW CTF 2014 - "saturn" Exploitation 400 Write-up


The description for this task was :

    You have stolen the checking program for the CSAW Challenge-Response-Authentication-Protocol system. Unfortunately you forgot to grab the challenge-response keygen algorithm ( Can you still manage to bypass the secure system and read the flag?

    nc 8888

I grabbed the binary , threw it in IDA and then started looking at the main routine. The first function that was called in main was _fillChallengeResponse and it takes two arguments . I named them : fill_arg0 and fill_arg4.
A quick check reveals that this function is imported from an external library (the one we 'forgot' to grab). Also by checking the arguments passed to the function they appear to be pointers , each pointer points to a 32 bytes array in the bss section.We can also see that the first array is directly followed by the next one.

As fillChallengeResponse is given 2 pointers , we can safely guess that its mission is to fill them with the right data.

Let's carry on :

Next, we will enter this loop. Its was previously initialized to 0 and we'll quit the loop only if the iterator is strictly above 0. In this loop, we are first prompted to supply an input in which only the first byte is read , the byte is saved at [esp+1Bh] and the switch statement only uses the highest order nibble of the read byte.
If the switch statement was supplied 0xA0 , it will lead to retrieving the original read byte (0xA2 for example) and then call a function that will access the Array1 and print the dword at the index described by the lowest order nibble of the read byte multiplied by 4 ((0xA2 & 0xF)*4 = 8 for example).
If the switch statement was supplied 0xB0 , the executed block of code will retrieve the original read byte and then call a function that will wait for user input and then compare that input to the dword indexed by the lowest orded nibble of the original byte multiplied by 4 in Array2. If the 2 values are equal another 8 sized array of bytes will be accessed and 1 is written into the same index indicated by the lowest order nibble.
If the switch statement was supplied 0x80 , it will call a function that walk through the array of bytes checking if all the elements are equal to 1. If it's the case , the function will print the contents of "flag.txt".

The trick here is to take advantage of the read_array1 function , to make it print the Array2 and then pass each dword read from Array2 to the check_array2 function. As we already know Array1 and Array2 are sticked to each other and each ones size is 16 bytes this means that supplying 0xA8 will make us read the first dword of the Array2 . So all we need to do is supply 0xA8 as an input , save the printed value from read_array1 function , supply 0xE0 as an input (switch) then supply the saved printed value as a input (in check_array2) , this will result in setting the first byte of the 8 bytes sized array to 1.
We have to  basically repeat the same 8 times , 0xA8 -> 0xAF and 0xE0 -> 0xE8. When done , we'll supply 0x80 as an input and the "target" function will print the flag for us.
Here's an automated python script which prints the flag :

Binary download : Here

Follow me on twitter : Here
- Souhail

CSAW CTF 2014 - Ish Exploitation 300 Write-up

This time with a quick writeup . Well , I took some time to reverse the binary under IDA and I soon discovered that the vulnerability was a memory leak which leaks 16 bytes from the stack and the vulnerable function was cmd_lotto, here's the full exploit :

I'll publish a writeup for exploitation 400 ( saturn ) as soon as possible.

Download binary : Here
Follow me on Twitter : Here

See you soon :).

- Souhail

Monday, September 15, 2014

NoConName 2014 - inBINcible Reversing 400 Writeup

We (Spiderz) have finished 26th at the NCN CTF this year with 2200 points and we really did enjoy playing. I was able to solve both cannaBINoid (300p) and (inBINcible 400p) .I have actually found 2 solutions for inBINcible that I'll describe separately later in this write-up.

We were given an 32-bit ELF binary compiled from Golang (GO Programming Language).
The main function is "text" (also called main.main) and it is where interesting stuff happens. While digging through this routine the os_args array caught my attention, around address 0x08048DB3 it will access the memory location pointed by os_args+4 and compare its content to 2. This value is nothing but the number of command line arguments given to the executable (argc in C), so the binary is expecting a command line argument which is in fact the key.
By looking at the next lines , I saw an interesting check :
.text:08048EFE                 mov     ebx, dword ptr ds:os_args
.text:08048F04                 add     ebx, 8
.text:08048F07                 mov     esi, [ebx+4]
.text:08048F0A                 mov     ebx, [esp+0C0h+var_54]
.text:08048F0E                 mov     ebp, [ebx+4]
.text:08048F11                 cmp     esi, ebp
.text:08048F13                 jz      loc_8049048
As it's the first time I encounter GOlang I though that it was better to use GDB alongside with IDA so I fired up my linux machine , put a breakpoint on  0x08048F11 , gave the binary a 4 bytes long command line argument (./inbincible abcd) and then I examined both ESI and EBP .
esi = 0x4
ebp = 0x10
You can easily notice tha abcd length is 4 and the right length that should be given is 16 , we can safely assume now that the flag length is 16 bytes.
Note :
The instruction which initializes the flag length to 0x10 is this one (examine instructions before it)
.text:08048D05                 mov     [ebx+4], edi

If the length check is true runtime_makechan function will be called (0x08049073) which creates a channel as its name implies. After that we'll enter immediately a loop that will get to initializing some structure fields then calling  runtime_newproc for each character in the flag (16 in total). One of the variables is initialized with  "main_func_001" and it can be seen as the handler that is called when chanrecv is called.
After breaking out of the loop, ECX is set to 1 and then we'll enter another loop (0x080490DD). This loop calls chanrecv for each character in the input (under certain circumstances). chanrecv is supplied the current index of the input and a pointer to a local variable which I named success_bool. Basically our main routine will supply a pointer to success_bool to the channel which will assign another thread (probably the one created using runtime_newproc) executing the main_func_001 to do some checks then write a TRUE or FALSE value into the variable. After returning from chanrecv the boolean will be checked. If it's TRUE ecx will keep its value ( 1 ) and we'll move to the next character. However if main_func_001 has set the boolean to false ecx will be zeroed and the other characters of the user input won't be checked (fail).
I have actually found 2 methods to approach this challenge (with bruteforcing and without bruteforcing) :

1 - Getting the flag using bruteforce :

This solution consists of automating the debugger (GDB) to supply a 16 bytes length string as an argument , the current character (we basically start with the first character) will be changed during each iteration using a charset and the next character will be left unchanged until we've found the right current character of the key and so on. To find the right character we must break after returning from chanrecv then read the local variable (boolean) value , if it's 1 then we've got the right character and we shall save it then move to the next one, else we'll keep looking until finding the right one.

Here's a python GDB script that explains it better :

flag : G0w1n!C0ngr4t5!!

2 - Getting the key by analyzing main_func_001 :

As main_func_001 is the one responsible for setting the boolean value, analyzing this routine will give us the possibility to get the flag without any bruteforcing. Let's see what it does :
main_func_001 expects the boolean variable pointer and the index of the character to be tested. This index , as mentionned earlier, is the iterator of the loop which has called chanrecv.
For the purpose of checking each character main_func_001 uses 2 arrays , I called the first 5 bytes sized array Values_Array. The second array size is 16 bytes , same length as the password.
So here's how we can get the flag using the 2 arrays :

flag : G0w1n!C0ngr4t5!!

The final key to validate the challenge is NcN_sha1(G0w1n!C0ngr4t5!!)

Binary download : Here

Follow me on Twitter : Here

See you soon :>

Friday, September 5, 2014

Windows Internals - A look into SwapContext routine

Here I am really taking advantage of my summer vacations and back again with a second part of the Windows thread scheduling articles. In the previous blog post I discussed the internals of quantum end context switching (a flowchart). However, the routine responsible for context switching itself wasn't discussed in detail and that's why I'm here today.

Here are some notes that'll help us through this post :
 1 - The routine which contains code that does context switching is SwapContext and it's called internally by KiSwapContext. There are some routines that prefer to call SwapContext directly and do the housekeeping that KiSwapContext does themselves.
 2 - The routines above (KiSwapContext and SwapContext) are implemented in ALL context switches that are performed no matter what is the reason of the context switch (preemption,wait state,termination...).
 3 - SwapContext is originally written in assembly and it doesn't have any prologue or epilogue that are normally seen in ordinary conventions, imagine it like a naked function.
 4 - Neither SwapContext or KiSwapContext is responsible for setting the CurrentThread and NextThread fields of the current KPRCB. It is the responsibility of the caller to store the new thread's KTHREAD pointer into pPrcb->CurrentThread and queue the current thread (we're still running in its context) in the ready queue before calling KiSwapContext or SwapContext which will actually perform the context-switch.
 Usually before calling KiSwapContext, the old irql (before raising it to DISPATCH_LEVEL) is stored in CurrentThread->WaitIrql , but there's an exception discussed later in this article.

So buckle up and let's get started :
Before digging through SwapContext let's first start by examining what its callers supply to it as arguments.
SwapContext expects the following arguments:
- ESI : (PKTHREAD) A pointer to the New Thread's structure.
- EDI : (PKTHREAD) A pointer to the old thread's structure.
- EBX : (PKPCR) A pointer to PCR (Processor control region) structure of the current processor.
- ECX : (KIRQL) The IRQL in which the thread was running before raising it to DISPATCH_LEVEL.
By callers, I mean the KiSwapContext routine and some routines that call SwapContext directly (ex : KiDispatchInterrupt).
Let's start by seeing what's happening inside KiSwapContext :
This routine expects 2 arguments the Current thread and New thread KTHREAD pointers in ECX and EDX respectively (__fastcall).
Before storing both argument in EDI and ESI, It first proceeds to save these and other registers in the current thread's (old thread soon) stack:
EBP : The stack frame base pointer (SwapContext only updates ESP).
EDI : The caller might be using EDI for something else ,save it.
ESI : The caller might be using ESI for something else ,save it too.
EBX : The caller might be using EBX for something else ,save it too.
Note that these registers will be popped from this same thread's stack when the context will be switched from another thread to this thread again at a later time (when it will be rescheduled to run).
After pushing the registers, KiSwapContext stores the self pointer to the PCR in EBX (fs:[1Ch]).Then it stores the CurrentThread->WaitIrql value in ECX, now that everything is set up KiSwapContext is ready to call SwapContext.

Again, before going through SwapContext let me talk about routines that actually call SwapContext directly and exactly the KiDispatchInterrupt routine that was referenced in my previous post.
Why doesn't KiDispatchInterrupt call KiSwapContext ?
Simply because it just needs to push EBP,EDI and ESI onto the current thread's stack as it already uses EBX as a pointer to PCR.

Here, we can see a really great advantage of software context switching where we just save the registers that we really need to save, not all registers.

Now , we can get to SwapContext and explain what it does in detail.
The return type of SwapContext is a boolean value that tells the caller (in the new thread's stack) whether the new thread has any APCs to deliver or not.

Let's see what SwapContext does in these 15 steps:

1 - The first thing that SwapContext does is verify that the new thread isn't actually running , this is only right when dealing with a multiprocessor system where another processor might be actually running the thread.If the new thread is running SwapContext just loops until the thread stops running. The boolean value checked is NewThread->Running and after getting out of the loop, the Running boolean is immediately set to TRUE.

2 - The next thing SwapContext does is pushing the IRQL value supplied in ECX. To spoil a bit of what's coming in the next steps (step 13) SwapContext itself pops ECX later, but after the context switch. As a result we'll be popping the new thread's pushed IRQL value (stack switched).

3 - Interrupts are disabled, and PRCB cycle time fields are updated with the value of the time-stamp counter. After the update, Interrupts are enabled again.

4 - increment the count of context switches in the PCR (Pcr->ContextSwitches++;) , and push Pcr->Used_ExceptionList which is the first element of PCR (fs:[0]). fs:[0] is actually a pointer to the last registered exception handling frame which contains a pointer to the next frame and also a pointer to the handling routine (similar to usermode), a singly linked list simply. Saving the exception list is important as each thread has its own stack and thus its own exception handling list.

5 - OldThread->NpxState is tested, if it's non-NULL, SwapContext proceeds to saving the floating-points registers and FPU related data using fxsave instruction. The location where this data is saved is in the initial stack,and exactly at (Initial stack pointer - 528 bytes) The fxsave output is 512 bytes long , so it's like pushing 512 bytes onto the initial stack , the other 16 bytes are for stack-alignment I suppose.The Initial stack is discussed later during step 8.

6 - Stack Swapping : Save the stack pointer in OldThread->KernelStack and load NewThread->KernelStack into ESP. We're now running in the new thread's stack, from now on every value that we'll pop was previously pushed the last time when the new thread was preparing for a context-switch.

7 - Virtual Address Space Swapping : The old thread process is compared with the new thread's process if they're different CR3 register (Page directory pointer table register) is updated with the value of : NewThread->ApcState.Process->DirectoryTableBase. As a result, the new thread will have access to a valid virtual address space. If the process is the same, CR3 is kept unchanged. The local descriptor table is also changed if the threads' processes are different.

8 -  TSS Esp0 Switching : Even-though I'll dedicate a future post to discuss TSS (task state segment) in detail under Windows , a brief explanation is needed here. Windows only uses one TSS per processor and uses only (another field is also used but it is out of the scope of this article) ESP0 and SS0 fields which stand for the kernel stack pointer and the kernel stack segment respectively. When a usermode to kernelmode transition must be done as a result of an interrupt,exception or system service call... as part of the transition ESP must be changed to point to the kernel stack, this kernel stack pointer is taken from TSS's ESP0 field. Logically speaking, ESP0 field of the TSS must be changed on every context-switch to the kernel stack pointer of the new thread. In order to do so, SwapContext takes the kernel stack pointer at NewThread->InitialStack (InitialStack = StackBase - 0x30) ,it substrats the space that it has used to save the floating-point registers using fxsave instruction and another additional 16 bytes for stack alignment, then it stores the resulted stack pointer in the TSS's Esp0 field : pPcr->TssCopy.Esp0 (TSS can be also accessed using the TR segment register).

9 - We've completed the context-switch now and the old thread can be finally marked as "stopped running" by setting the previously discussed boolean value "Running" to FALSE. OldThread->Running = FALSE.

10 - If fxsave was previously executed by the new thread (the last time its context was switched), the data (floating-point registers...) saved by it is loaded again using xrstor instruction.

11 - Next the TEB (Thread environment block) pointer is updated in the PCR :
pPcr->Used_Self = NewThread->Teb . So the Used_Self field of the PCR points always to the current thread's TEB.

12 - The New thread's context switches count is incremented (NewThread->ContextSwitches++).

13 - It's finally the time to pop the 2 values that SwapContext pushed , the pointer to the exception list and the IRQL from the new thread's stack. the saved IRQL value is restored in ECX and the exception list pointer is popped into its field in the PCR.

14 - A check is done to see if the context-switch was performed from a DPC routine (Entering a wait state for example) which is prohibited. If pPrcb->DpcRoutineActive boolean is TRUE this means that the current processor is currently executing a DPC routine and SwapContext will immediately call KeBugCheck which will show a BSOD : ATTEMPTED_SWITCH_FROM_DPC.

15 - This is the step where the IRQL (NewThread->WaitIrql) value stored in ECX comes to use. As mentionned earlier SwapContext returns a boolean value telling the caller if it has to deliver any pending APCs. During this step SwapContext will check the new thread's ApcState to see if there are any kernel APCs pending. If there are : a second check is performed to see if special kernel APCs are disabled , if they're not disabled ECX is tested to see if it's PASSIVE_LEVEL, if it is above PASSIVE_LEVEL an APC_LEVEL software interrupt is requested and the function returns FALSE. Actually the only case that SwapContext returns TRUE is if ECX is equal to PASSIVE_LEVEL so the caller will proceed to lowering IRQL to APC_LEVEL first to call KiDeliverApc and then lower it to PASSIVE_LEVEL afterwards.

Special Case :
This special case is actually about the IRQL value supplied to SwapContext in ECX. The nature of this value depends on the caller in such way that if the caller will lower the IRQL immediately upon returning from SwapContext or not.
Let's take 2 examples : KiQuantumEnd and KiExitDispatcher routines. (KiQuantumEnd is the special case)

If you disassemble KiExitDispatcher you'll notice that before calling KiSwapContext it stores the OldIrql (before it was raised to DISPATCH_LEVEL) in the WaitIrql of the old thread so when the thread gains execution again at a later time SwapContext will decide whether there any APCs to deliver or not. KiExitDispatcher makes use of the return value of KiSwapContext (KiSwapContext returns the same value returned by SwapContext) to lower the IRQL. (see step 15 last sentence).
However, by disassembling KiQuantumEnd you'll see that it's storing APC_LEVEL at the old thread's WaitIrql without even caring about in which IRQL the thread was running before. If you refer back to my flowchart in the previous article you'll see that KiQuantumEnd always insures that SwapContext returns FALSE , first of all because KiQuantumEnd was called as a result of calling KiDispatchInterrupt which is meant to be called when a DISPATCH_LEVEL software interrupt was requested.Thus, KiDispatchInterrupt was called by HalpDispatchSoftwareInterrupt which is normally called by HalpCheckForSoftwareInterrupt. HalpDispatchSoftwareInterrupt is the function responsible for raising the IRQL to the software interrupt level (APC_LEVEL or DISPATCH_LEVEL) and upon returning from it HalpCheckForSoftwareInterrupt recovers back the IRQL to its original value (OldIrql). So the reason why KiQuantumEnd doesn't care about KiSwapContext return value because it won't proceed to lowering the IRQL (not its responsibility) nor to deliver any APCs that's why it's supplying APC_LEVEL as an old IRQL value to SwapContext so that it will return FALSE. However, a software interrupt might be requested by SwapContext if there are any pending APCs.
KiDispatchInterrupt which calls SwapContext directly uses the same approach as KiQuantumEnd, instead of storing the value at OldThread->WaitIrql it just moves it into ECX.

Post notes :
- Based on Windows 7 32 bit :>
- For any questions or suggestions feel free to leave a comment below or send me an email :

See you again soon :)
